600W Power Supply for Z420 Workstation
This Genuine OEM 600W internal power supply is designed for compatible Z420 Workstation configurations. It features proprietary 18-pin and 8-pin system connections, two 6-pin graphics power connectors, six SATA connectors, and one legacy IDE/PATA power connector.
Technical Specifications
Product Type: Internal workstation power supply
Testing Status: Cleaned and fully tested
Warranty: CPU Medics 30-Day Limited Warranty
Maximum Output Power: 600W
Form Factor: Proprietary workstation PSU
Standard AC Input: 100-240V AC 8.0A 50-60Hz
Alternate AC Input: 118V AC 8.0A 400Hz
AC Inlet: IEC 60320 C14
Dimensions: Approximately 150mm x 98mm x 168mm
Cooling: Integrated internal fan
Installation Type: Internal screw-mounted power supply
Required Power Cord: NEMA 5-15P to IEC C13 power cord sold separately
DC Output
+12V G1 Rail: 18.0A
+12V CPU Rail: 18.0A
+12V S Rail: 18.0A
-12V Rail: 0.15A
+12V M Rail: 18.0A
+12V G2 Rail: 18.0A
+11V Standby Rail: 1.75A
+12V B Rail: 18.0A
Connector and Cable Layout
P1 System Connector: One 18-pin connector with an approximately 18-inch cable
P2 System Connector: One 8-pin connector with an approximately 4-inch cable
G1 Graphics Connector: One 6-pin connector with an approximately 22-inch cable
G2 Graphics Connector: One 6-pin connector with an approximately 22-inch cable
D7 IDE/PATA Connector: One connector with an approximately 16.5-inch cable
First SATA Cable: D1 at approximately 21 inches, D2 at 23 inches, and D3 at 25 inches
Second SATA Cable: D4 at approximately 7 inches, D5 at 10.5 inches, and D6 at 14 inches
Total SATA Connectors: Six
Interchangeable / Replacement Part Numbers
623193-001, 632911-001, DPS-600UB A, DPS-600UBA
