Description:
HP 800GB 2.5-inch SFF NVMe x4 Lanes SSD
Mainstream Performance (MP)
Mixed-Use (MU) Digitally Signed Firmware (DS)
NVMe Solid State Drive (SSD) in
G9 G10 G10+ (Gen9 Gen10 Gen10-Plus)
Hot-Plug SmartDrive Carrier NVMe (SCN) (as pictured)
Genuine HP serial number and SSD firmware
Genuine HP Certified NVMe SCN SSD (Solid State Drive)
Part Number(s)
Option Part# 875595-B21
SmartBuy Part# 875595-S21
Spare Part# 875875-001
Assembly Part# 869253-002
Model# MK000800KWDUL
Overview:
HPE NVMe Mainstream Performance (MP) Mixed Use (MU) Solid State Drives are best
suited for high I/O applications that require a balanced performance
between reads and writes to deliver high performance and endurance for
data intensive applications. NVMe MU SSDs communicate directly to
applications via the PCIe bus to boost I/O bandwidth and reduce latency.
HPE NVMe Mainstream Performance (MP) SSDs are advanced data center
drives optimized for greater performance and endurance in a
cost-effective design. Designed to utilize the high bandwidth of PCIe
Gen3 and PCIe Gen4 in select servers for mixed use workloads requiring
outstanding IOPS per watt and cost per IOPS as an upgrade from SATA SSDs.
Specifications:
CategoryProliant HardDrive
Sub-CategorySolid State Drive
GenerationNVMe SCN SSD
Part Number875595-B21
Best Use: Mixed-Use
Manufacturer:Hewlett Packard
Products ID711232
Plug TypeHot Plug
Form Factor2.5 inches / SFF
Capacity800GB
Interface TypeNVMe
Workload TypeMixed Use
Carrier TypeSCN
Flash TypeTLC
PortSingle
This HP Part# 875595-B21 is compatible with these HP G9/G10 HP Servers and Storage Systems
Proliant BL Series: BL460c (G9 G10) BL660c (G9)
Proliant DL Series: DL325 (G10+) DL360 (G9 G10)
Proliant DL Series: DL380 (G9 G10) DL385 (G10 G10+)
Proliant DL Series: DL560 (G9 G10) DL580 (G9 G10)
Proliant ML Series: ML350 (G9 G10)
Apollo Series: 4500 (G10) 4510 (G10) 4520 (G10) 4530 (G10)
Apollo Series: k6000 (G10) d6500 (G10) r2200 (G10) r2600 (G10) r2800 (G10)
